CLINY

Transanal Ileus Decompression Tube Set(for Large intestine)

Features and advantages

1.Facilitating transanal approach
Dedicated (specific) dilator for dilating stenosis (DDS) extends the stenosis into which decompression tube can be easily inserted.

2.Producing higher decompression effect
Opened tip (end opening) and 4-6 side openings facilitate efficient suction of content. During suction, the air vent prevents excessive depressing pressure from acting on the intestine.

3.Two-channel connector for easier irrigation and drainage.
The two-channel connector allows easier and more hygienic irrigation and drainage procedure after a decompression tube is placed.

4.Contrast rings for locating the balloon.
The contrast rings at the both ends of the balloon are useful for locating the balloon.

5.One-way valve for preventing the backflow of intestinal contents
The one-way valve prevents the backflow of intestinal contents through the air vent lumen.

Enlarge product image

  • 432_ext_02_0.jpg
  • 432_ext_02_1.jpg
  • 432_ext_02_2.jpg
  • 432_ext_02_3.jpg

Specification

Transanal Ileus Decompression Tube Set
Product Code Decompression Tube Guide wire Dilator for opened
forceps
Dilator for dilating
stenosis
002 380 0220 22Fr (7.3mm), L-1,200mm - 2,000mm,
Balloon Capacity : 30mL,
Open tip, with 4 - 6 side holes
0.052"
(1.32mm)x
L-3,000mm
8Fr(2.7mm)x
L-2,000mm - 4,000mm
26Fr(8.6mm)x
L-1,000mm,
with radiopaque tip

1 set per box, Sterilized with EtO Gas

Transanal Decompression Tube
Product Code Size Total length Side hole Tip shape Balloon
capacity
002 385 0220 22Fr (7.3mm) 1,200mm - 1,690mm 4 - 6 side holes Open tip 30mL

1 piece per box, Sterilized with EtO Gas

Transanal Ileus Decompression Tube Set (ST Type)
Product Code Decompression Tube Guide wire Dilator for opened
forceps
Dilator for dilating
stenosis
002 381 0220 22Fr (7.3mm), 30mL ,
L-1,200mm - 2,000mm,
Balloon Capacity : 30mL,
Open tip, with 4 - 6 side holes
0.052”
(1.32mm)x
L-3,000mm
8Fr(2.7mm)x
L-2,000mm - 4,000mm
26Fr(8.6mm)x
L-1,000mm,
with radiopaque tip

Capable of penetrating into sliding tube. 1 set per box, Sterilized with EtO Gas

Transanal Decompression Tube (ST Type)
Product Code Size Total length Side hole Tip shape Balloon
capacity
002 386 0220 22Fr (7.3mm) 1,200mm - 1,690mm 4 - 6 side holes Open tip 30mL

Capable of penetrating into sliding tube. 1 piece per box, Sterilized with EtO Gas
